XCJ Series Planetary Differential Gearboxes

This product series features a differential planetary structure, characterized by its compact design, high load-bearing capacity, gear modification for larger contact ratios, and low noise. The interior of the gearbox is optimized to transform and decompose the input motions from hoisting motors, opening/closing motors, and traveling motors into different rotational directions and speed combinations for four drums. This controls a series of actions such as the hoisting, opening/closing, and traveling of grabs, making it a key piece of equipment for bridge-type grab ship unloaders.

Features:

Modular design, compact structure, short lead time;

Unique gear modification technology for improved meshing performance, providing smoother transmission and lower noise;

Hard tooth surface design meets the high standards of ISO, AGMA, and DIN;

Various lubrication configurations to meet the demands of different operating conditions;

A selection of accessories is available to meet different requirements at a high cost-performance ratio.

Main Technical Parameters:

Speed ratio range: 11.2–50

Center distance between the two output shafts: 800–2,800 (mm)

Maximum loading and unloading capacity: 5,000 t/h

Main Fields of Application:

Bridge-type grab ship unloaders.
