In the field of industrial transmission, the assembly process of precision planetary reducers directly affects their performance and service life. MVBR060L2 precision planetary reducer has been widely used in many fields due to its excellent quality and performance. Below is an introduction to its standard assembly process.

1、 Preparation work before assembly

1. Parts inspection

Strictly inspect all parts, including gears, shafts, bearings, housings, etc. Ensure that the parts are free from damage, deformation, and dimensional accuracy meets the requirements. At the same time, check the surface quality of the parts to ensure that there is no rust, oil stains, etc.

2. Cleaning work

Clean all parts to remove surface oil stains, impurities, etc. Cleaning agents can be used for cleaning, and then wiped dry with a clean cloth. Ensuring the cleanliness of the parts is crucial for ensuring the assembly quality of the gearbox.

3. Tool preparation

Prepare the necessary tools for assembly, such as wrenches, screwdrivers, hammers, jacks, etc. Ensure the accuracy and reliability of the tools to ensure the smooth progress of the assembly process.

2、 Assembly process

1. Box assembly

Assemble the various parts of the box to ensure its sealing and strength. During the assembly process, attention should be paid to the flatness of the joint surface of the box, the correct installation of the sealing gasket, and the tightening of bolts according to the specified torque.

2. Gear installation

Install the gears onto the shaft in the correct order and direction. During installation, it is important to ensure that the meshing clearance of the gears meets the requirements and that the axial positioning of the gears is accurate. Special tools can be used for gear installation and adjustment.

3. Bearing installation

Install the bearings onto the shaft and housing. During the installation process, it is important to pay attention to the correct installation direction of the bearings and ensure that the clearance of the bearings meets the requirements. Special tools can be used for the installation and adjustment of bearings.

4. Installation of shaft

Install the shaft with installed gears and bearings onto the housing. During installation, it is important to ensure accurate axial positioning of the shaft and flexible rotation of the shaft. Specialized tools can be used for shaft installation and adjustment.

5. Installation of other components

Install other components of the gearbox, such as seals, oil gauges, drain plugs, etc. During the installation process, attention should be paid to the correct installation position of each component and the installation should be firm.

3、 Inspection work after assembly

1. Appearance inspection

Inspect the appearance of the assembled gearbox to ensure that the surface of the gearbox is free from damage, deformation, oil stains, etc. At the same time, check that the installation positions of each component of the reducer are correct and the installation is firm.

2. No load test

Conduct a no-load test on the assembled reducer to check whether the rotation of the reducer is flexible, and whether there are any abnormal noises and vibrations. During the no-load test, attention should be paid to observing the temperature changes of various parts of the gearbox to ensure that the temperature of the gearbox is within the normal range.
